DIGISOL Systems has launched its new 90-degree UTP Patch Panels under its Structured Cabling Systems (Passive) range. DIGISOL UTP Patch Panels have 90-Degree (Top Entry) punch down design for convenient network terminations. DIGISOL Patch Panels have integral cable management shelf ensured for bend radius compliance. Exceeds ANSI/TIA/EIA-568-C.2 Standard and supports 1000-Base-T. DIGISOL’s patch panels have 6x4 module specially designed jack configuration and accommodates 22~26 AWG stranded and solid wires.



Patch Panels are used to terminate a variety of low-voltage Ethernet cables like Cat5e, Cat6, Cat6A near Ethernet switch, mounting inside the Network Rack. PCB based loaded or pure unloaded patch panels are preferred to terminate higher bunches of cable, generally 6, 12, 24 and 48 ports. It is available in 1U or 2U height. Loaded patch panels are generally available in removable or fixed modular type. 180 Deg patch panels have IDCs (Insulation Displacement Contacts) at the back side of panel, whereas 90 Deg (Top Entry) Patch Panels have IDCs (Insulation Displacement Contacts) perpendicular. This degree is derived from the angle between the front side Ethernet patch cord and position of punching tool to terminate the horizontal cable, generally pulled from 305 mtrs cable boxes.



DIGISOL SCS products adhere to EIA/TIA and ISO/IEC international standards. ROHS- compliant products are backed by international 25 years product performance warranty.



These Patch Panels are available in Cat5e, Cat6 and Cat6A type.
