Canon intros new Firmware and Applications for 4K Remote PTZ Camera Systems

Canon India announced that they will begin offering firmware updates in early July 2024 to enhance functions and performance, including auto tracking, for its 4K remote PTZ cameras and remote camera controllers. Notably, the firmware will include a limited feature version of the Auto Tracking Add-On Application on supported cameras at no charge.

Canon India has been enhancing its product line-up of remote PTZ camera systems by providing application software that adds necessary functions according to their usage to camera systems, including 4K remote PTZ cameras and specialised controllers. With upgrades to firmware and applications across the system to improve their respective functionality and performance, Canon aims to assist workflow improvements on video production projects and aid visual communication in situations such as web conferences and lecture broadcasts.

Enhanced Auto Tracking Performance and Free Auto Tracking Application (Lite)

Enhancements to the Auto Tracking Add-On Application results in smoother, more natural pan tilt movement, and algorithm improvements to help maintain tracking of the desired subject even when crossing paths with others. Additionally, detailed auto tracking settings can now be adjusted from the controller, enabling operation without a PC. Canon will also be including in the firmware update a free lite version of the Auto Tracking Add-On application. Named Auto Tracking Application (Lite), this free version provides the same smooth and precise auto tracking experience as the paid version, but without some of the advanced customizations that are available in the full licensed version.

CR-N100 & CR-N300 Improved Frame Rate for USB Camera Output

The CR-N100 and CR-N300 will also see some significant improvements with this firmware. Their performance when in USB webcam mode will see a significant boost with higher frame rates and the addition of YUV format, which facilitates easier post-shooting image processing, making them versatile for various web conferencing applications in the Corporate and Education markets.

Improved Camera Control Experience

The remote camera controller RC-IP1000 will now be able to display thumbnail images of the camera's registered preset/trace functions on its touch panel. This allows for intuitive control by reducing operation errors when recalling functions based on thumbnail images. Additionally, up to nine camera feeds displayed on the touch panel can be output to external monitors via SDI and HDMI. This capability enhances on-site operational convenience by enabling control while viewing multi-camera displays on large screens.

Key Features of the Firmware and Applications

Enhanced Auto Tracking with Improved Performance, Precision, and Usability

Improved algorithms enhance the ability to track a subject even when individuals cross paths in front of or behind the subject during live broadcasts of talk shows, concerts, etc., ensuring continuous tracking of the intended subject without switching to others.

Provides smooth and natural tracking movements when starting and stopping, achieving high-quality camera work without compromising tracking performance.

Allows selection of the tracking target when multiple subjects are detected and setting of the target's display position using silhouette display, all operable from the RC-IP1000 controller. Enables auto tracking control without a PC, improving operational efficiency. Similar settings can also be operated from the PC application Remote Camera Control Application.

Both the RC-IP1000 and Remote Camera Control Application can display the camera crop frame6 while setting the target's display position using silhouette display. This facilitates easy composition combining camera crop and auto tracking. It maintains high tracking performance with a wide angle while achieving dynamic close-up shots with camera crop.

Auto Tracking Application (Lite), which has the basic features of the Auto Tracking Application RA-AT001 will be available for free for all indoor remote PTZ camera models. Updating the firmware of the remote PTZ camera will enable the use of Auto Tracking Application (Lite).

Easy Composition Adjustment by Superimposing Camera Crop Frame and Auto Tracking Silhouette Display

Improved Frame Rate for USB Camera Output

The frame rate for video output via UVC connection on the CR-N300 and CR-N100 has been increased from the previous maximum of FHD 12.5fps to a new maximum of FHD 30fps, enabling smooth and high-quality video streaming.

In addition to the Motion JPEG format, the cameras now support the YUV format, which can be used for various web conferencing applications.

Expanded Touch Panel Display and External Output Functions for Controllers

Thumbnail Image Display on Touch Panel

In the preset/trace functions, which pre-register positions and movements for pan, tilt, and zoom, the registered video can now be displayed as thumbnail images on the touch panel. These thumbnail images can be used to replay functions via panel touch or operation buttons, reducing operation errors. Furthermore, these thumbnail images can be output to external monitors via SDI and HDMI.

The 2x2 and 3x3 multi-view screens displayed on the touch panel can be output to external monitors via SDI and HDMI. The number of camera feeds that can be output to an external monitor has increased from one to a maximum of nine, allowing flexible operation such as displaying the settings menu on the touch panel while viewing multi-view screens on a large monitor.

The firmware update adds support for Elgato Stream Decks. The RC-IP1000 can connect directly to Elgato's "Stream Deck7" via USB. Functions such as preset, multi-preset, and camera selection that can be operated from the RC-IP1000 can be assigned to each button on the "Stream Deck" for one-touch operation.

The expansion of Canon's proprietary IP "XC Protocol" allows integration with external control systems, enabling control and status information retrieval of the RC-IP1000. This supports the construction of more flexible and compatible systems when combining remote PTZ camera systems with external products.

During manual focus, a focus guide can be displayed on the touch panel, allowing visual confirmation of focus while operating. Camera setting information can also be displayed as OSD, allowing confirmation of camera settings while viewing video on the touch panel.

Additional assist functions have been added to support the operator's tasks. These include a waveform monitor and vectorscope to check if video contrast and colour is correctly adjusted, and markers (centre marker/grid marker/area marker) that are useful for setting the composition of the video, all of which can be displayed on the touch panel. These assist functions can also be output to external monitors via SDI and HDMI8.

Free Provision of Basic Features of the Auto Tracking Application

We will begin offering Auto Tracking Application (Lite), which has the basic features of the paid "Auto Tracking Application RA-AT001" for free while maintaining its tracking performance. The main differences in functionality are as follows.
